-4%
|
Model Name
|
KSV-12TPINV-SW
|
|||||
|
Type
|
Cooling only
|
|||||
|
Control type
|
Remote
|
|||||
|
Power supply
|
Ph-V-Hz
|
1Ph-220-240V~50Hz
|
||||
|
Voltage Range
|
V
|
198~242
|
||||
|
Cooling |
Capacity
|
Btu/h
|
12000(2730~12500)
|
|||
|
Capacity
|
W
|
3200(800~3665)
|
||||
|
Rated power input
|
W
|
994(250~1450)
|
||||
|
Rated current
|
A
|
4.6(1.2~7.5)
|
||||
|
EER
|
W/W
|
3.22
|
||||
|
Max power input
|
W
|
1450
|
||||
|
Max current
|
A
|
7.5
|
||||
|
Indoor coil
|
a.Number of rows
|
2
|
||||
|
b.Tube pitch(a)x row pitch(b)
|
mm
|
21×12.7
|
||||
|
c.Fin spacing
|
mm
|
1.5
|
||||
|
e.Tube outside dia. and type
|
mm
|
Φ7,inner groove tube
|
||||
|
f.Coil length x height x width
|
mm
|
/
|
||||
|
g.Number of circuits
|
1 in 2 out
|
|||||
|
Outdoor coil
|
a.Number of rows
|
1
|
||||
|
b.Tube pitch(a)x row pitch(b)
|
mm
|
19.5×11.6
|
||||
|
c.Fin spacing
|
mm
|
1.2
|
||||
|
e.Tube outside dia. and type
|
mm
|
Φ5,inner groove tube
|
||||
|
f.Coil length x height x width
|
mm
|
/
|
||||
|
g.Number of circuits
|
1 in 1 out
|
|||||
|
Indoor unit
|
Dimension(W*D*H)
|
mm
|
776×250×202
|
|||
|
Packing   (W*D*H)
|
mm
|
840×315×260
|
||||
|
Net/Gross weight
|
Kg
|
8/10
|
||||
|
Outdoor unit
|
Dimension(W*D*H)
|
mm
|
787×290×498
|
|||
|
Packing  (W*D*H)
|
mm
|
818×325×520
|
||||
|
Net/Gross weight
|
Kg
|
22/26
|
||||
|
Refrigerant piping
|
Liquid side/ Gas side
|
mm(inch)
|
φ6(1/4″)/φ9.52(3/8″)
|
|||
|
Max. refrigerant pipe length
|
m
|
15
|
||||
|
Max. difference in level
|
m
|
5
|
||||
|
Pressure
|
High(DP)
|
MPa
|
4.5
|
|||
|
Low(SP)
|
MPa
|
1.9
|
||||
|
Refrigerant
|
R410A/0.53kg
|
|||||
|
Ambient temperature
|
℃
|
-15~50
|
||||
|
Suitable area
|
m2
|
15~23
|
||||
|
Connecting Wiring
|
|
4×1.0mm²×5.8m
|
||||
|
Power supply cord
|
AWG16
|
|||||
|
310
|
|||||
